Ball Screw LM Guide Linear Bushing

Ball Screw

LM Guide

Linear Bushing

The Ball Screw is a high-efficiency feed screw with the ball making a rolling motion between the screw axis and the nut. Compared with a conventional sliding screw, this product has drive torque of one-third or less, making it most suitable for saving drive motor power. LM Guide(full-ball type) A series of types are available from miniature types to large types for machine tools, from linear guides to curved guides that suit a wide-range of applications. The Linear Bush is a linear guide used in combination with a LM shaft that has a cylindrical shaft. This product makes linear movements with a minimum of frictional resistance to provide highly accurate and supple movement.


Please note: Products are currently sold to continental U.S., Canada, and Mexico customers only.

Visit Our Booths! 2012 Event Schedule

ACTUATOR

Lightweight, high rigidity aluminum base with Caged Ball LM Guides has been utilized for the guide portion. A screw or belt options are available for the drive system. In addition, Caged Ball LM Guides and QZ Lubricator for the Ball Screw has been utilized to provide a long-term maintenance free actuator.
GL20N-046-HV-B40Q-B-N-N-N-Y VLACT35-06-0050-0-0N

GL20N-046-HV-B40Q-B-N-N-N-Y

VLACT35-06-0050-0-0N

Model = GL20N, 460 mm, HV = SHS-V (L-type), B40 = Ball Screw lead 40 mm (GL20 only)Q, B = B: inner diam 50H7, M5, PCD70, N = None
Model = VLA-CT-35, 50 mm

Caged Ball LM Guide

SRS20MUU+1000LM SSR20XV1UU+1000L SHS20C1UU+1000L

SRS20MUU+1000LM

SSR20XV1UU+1000L

SHS20C1UU+1000L

Model : SRS 20M, Length : 1000 mm, Seal type : UU, QZ : No, Clearance : None
Model : SSR20XV, Length : 1000 mm, Seal type : UU, QZ : No
Model : SHS 20C, Length : 1000 mm, Seal type : UU, QZ : No
