Note 1: The dynamic permissible torque (T) indicates the torque at which the contact surface pressure on the spline teeth is 9.8 N/mm2.
Clearance in the rotational direction: α ≤20' MAX. If multiple spline nuts are to be mounted on a single shaft, please note that the locations of flange mounting holes and
key grooves on the respective spline nuts may vary slightly. Avoid designs that would require fitting multiple spline nuts to a single housing.For more detailed specifications, please download the Product Catalog with the link in the Downloads section of this product page.
